GYFTY Outdoor Fiber Optic Cable 24 Core G652D Non-Metallic Self Supporting Cable
Product Features
Non-metallic structure for strong anti-electromagnetic interference
High-strength loose tube with water-blocking protection
Lightweight and small diameter for easy installation
UV-resistant PE sheath for reliable outdoor durability
Application Scenarios
Power transmission and high-voltage environments
Areas with strong electromagnetic interference
Overhead telecom and backbone networks
Long-distance outdoor communication systems
Optical Characteristics
| Items | Unit | Specification | |
| G652D | |||
| Mode Field Diameter | 1310nm | um | 9.2±0.4 |
| 1550nm | um | 10.4±0.5 | |
| Cladding Diameter | um | 124.8±0.7 | |
| Cladding Non-Circularity | % | ≤0.7 | |
| Core-Cladding Concentricity Error | um | ≤0.5 | |
| Coating Diameter | um | 245±5 | |
| Coating Non-Circularity | % | ≤6.0 | |
| Cladding-Coating Concentricity Error | um | ≤12 | |
| Cable Cutoff Wavelength | nm | acc≤1260 | |
| Attenuation(max.) | 1310nm | dB/km | ≤0.36 |
| 1550nm | dBkm | ≤0.22 | |
Technical Parameters
| Fiber Count |
Diameter (MI) |
Weight (KG/KMI) |
Min.Bend Radius | Mlin.Tension (N) |
Crush (N/100MMl) |
|||
| Static | Dynamic | Long Term | Short Term | Long Term | Short Term | |||
| 2-30 | 8.8 | 88 |
10
|
20
|
1500 | 800 | 1000 | 500 |
| 32-36 | 9.0 | 95 | 1500 | 800 | 1000 | 500 | ||
| 38-60 | 9.2 | 98 | 1500 | 800 | 1000 | 500 | ||
| 62-72 | 9.5 | 105 | 1500 | 800 | 1000 | 500 | ||
| 74-96 | 10.5 | 118 | 1500 | 1000 | 1000 | 500 | ||
| 98-120 | 11.8 | 145 | 2000 | 1500 | 1000 | 500 | ||
| 122-144 | 14.2 | 165 | 2000 | 1500 | 1000 | 500 | ||
| 146-216 | 16.3 | 225 | 2000 | 1500 | 1000 | 500 | ||
| 218-240 | 18.5 | 305 | 2000 | 1500 | 1000 | 500 | ||
| 242-288 | 22.7 | 395 | 2500 | 2000 | 1000 | 500 | ||
Detail product pictures
FAQ – GYFTY Fiber Optic Cable
Q1: What is GYFTY cable used for?
A: It is used for outdoor telecom networks and power line communication systems.
Q2: What fiber types are available?
A: G652D single-mode and multimode fibers such as OM1, OM2, OM3, and OM4.
Q3: Is it suitable for outdoor use?
A: Yes, it has a UV-resistant PE sheath and waterproof structure.
Q4: Does the cable resist interference?
A: Yes, the non-metallic design provides strong anti-electromagnetic interference.
Q5: Do you support OEM orders?
A: Yes, OEM customization is available.
